Precision Carbon Dioxide IAQ Monitoring Data Logger

Description

The 1% Carbon Dioxide Sampling Data Logger is designed to measure carbon dioxide concentrations in enclosed environments such as indoor air quality and HVAC applications.

Features

• Instant CO2 sampling – gain measurements in seconds!
• User programmable to measure at specific intervals
• Data Logging with micro SD Card (16GB included), with real-time graphing
• Li-ion rechargeable batteries lasting 30+ hours (3 included)

Applications

• Indoor Air Quality
• HVAC
• Scientific Research

Specifications

• Sensing method: NDIR (Non-Dispersive Infrared)
• Measures: CO2 – 1% (0-10,000ppm) CO2
• Relative Humidity: 0~95%, ±3% @25°C (20~80%RH), others ±5%
• Temperature: 0~50°C,±1℃
• Barometer: 50~110kPa, ±0.4kPa
• Display Resolution: CO2: 1ppm, 10ppm, or 100ppm
• Accuracy: ±70 ppm +/- 5% of reading @ STP
• Alarm Volume: 80db ±5% @10cm
• Display Resolution: CO2:  1ppm, 10ppm, or 100ppm
• Operating Conditions: 0~50°C(32~122°F), 0~95%RH, non-condensing
• Storage Temperature: -20~60°C(-4~140°F)
• Power: (3) Li-ion 18650 Batteries
• Weight: 305g (without batteries)
• Dimensions: 225.8 x 99.6 x 55 mm (8.9 x 3.9 x 2.2 in.)

Includes

• Handheld CO2 Sampling Data Logger Detector
• Manual
• USB 1.5m Cable
• 3 Li-Ion Batteries
• 16 GB SD Card – required for calibration files
• Tubing – 3m 1/8″ ID x 1/4″ OD x 1/15″ Wall Clear PVC Tubing
• Hydrophobic and Particulate Filters
• Water Trap

Warranty

• 1 year – See CO2Meter Terms and Conditions.

Documents

Datasheet (pdf)

Manual (pdf)

GasLab Pro Pump Notice (pdf)

GasLab Pro Calibration SD Card Notice (pdf)

CM-1000 Video Playlist – Settings, Data Logging, Calibration (web)

Software Options

This device features data logs that are stored on a micro SD Card.

Our GasLab® Software is not compatible with this device.

Accessories

• BAT-18650 – EBL 18650 3.7V Li-ion Rechargeable Batteries – provide a fast charge and are upgraded ETL certified to be used with all CM-500 and CM-1000 series handheld gas detectors.
• EBL Universal Battery Charger – Charge the lithium batteries via a USB cable. Provides a clear indication of charge levels, turning green after fully charged.
